How to Unbrick and Resolve Software Issues on OnePlus 11 5G (Models: PHB110 firmware, CPH2447 firmware, CPH2449 firmware, CPH2451 firmware) Using Stock ROM Firmware (Flash File)
This process involves using the official Stock ROM firmware to address and resolve various software-related issues on the OnePlus 11 5G. By utilizing the firmware, you can effectively fix problems such as system freezes on the logo screen, FRP lock resets, fastboot mode errors, bootloop issues (including lost fastboot or recovery), and being stuck in EDL mode (resulting in a black screen).
Table of Contents
Prerequisites for How to Unbrick OnePlus 11 5G
Before proceeding with the unbricking process, ensure that you have the following:
- MSM Tool: The official Mobile Software Management tool from OnePlus. You can obtain this from official OnePlus sources or authorized distributors. It is crucial to use the correct version specific to the OnePlus 11 5G.
- A Windows PC: The MSM Tool is designed to run on Windows computers, so you will need a reliable PC running Windows 7 or later.
- USB Cable: A high-quality USB cable to connect the OnePlus 11 5G to the PC.
- Battery Charged Above 10%: It is recommended to ensure that the OnePlus 11 5G has sufficient battery charge. If the phone is completely powered off or bricked, this is less critical, but it helps prevent interruptions during the process.
- Qualcomm Drivers: These drivers are essential for enabling communication between the OnePlus 11 5G and the computer. Install them before proceeding.
- Firmware for OnePlus 11 5G: The correct firmware files for your device. If necessary, download the appropriate firmware package from trusted sources or OnePlus support channels.
Step-by-Step Process for How to Unbrick OnePlus 11 5G Using the MSM Tool
- Download and Install the MSM Tool
Start by downloading the MSM Tool compatible with the OnePlus 11 5G. Once downloaded, extract the zip file to a folder on your PC. - Install Qualcomm USB Drivers
Go to Device Manager on your Windows PC.
Right-click the Start Menu, then select Device Manager.
Look for Unknown Device or your OnePlus 11 5G under the “Ports” or “Other devices” section.
Right-click it, select Update Driver, and install Qualcomm USB drivers. You can download the drivers from trusted sources like the Qualcomm website. - Boot OnePlus 11 5G into EDL (Emergency Download Mode)
OnePlus devices need to be in EDL mode to communicate with the MSM Tool. Here’s how to put the OnePlus 11 5G into EDL mode:- Power off the OnePlus 11 5G completely.
- Hold down the Volume Up button and connect the phone to the PC using a USB cable.
- Once connected, the device should enter EDL mode, and the MSM Tool should detect the phone automatically.
- Launch the MSM Tool
After successfully connecting the OnePlus 11 5G in EDL mode, open the MSM Tool you downloaded earlier. The interface should display your connected device. If it’s not detected, ensure that the Qualcomm drivers are installed correctly and try again. - Start the Unbricking Process
In the MSM Tool interface, you will see the Start or Download button. Click it to begin the unbricking process.
The tool will start flashing the firmware to the OnePlus 11 5G. This may take a few minutes, depending on the speed of your computer and the device. - Wait for the Process to Complete
During the flashing process, the MSM Tool will show progress in percentages. Be patient and avoid disconnecting the device during this process. Disconnecting the device prematurely may cause further bricking or system software corruption. - Reboot the Device
Once the MSM Tool displays a message indicating the process is complete, you can safely disconnect the OnePlus 11 5G from the PC. The device should now boot into the operating system, free from the bricked condition. If the device doesn’t boot immediately, it may require a few more minutes.
Troubleshooting
- Device Not Entering EDL Mode: If the OnePlus 11 5G isn’t entering EDL mode, double-check the steps or try using a different USB cable or port.
- MSM Tool Doesn’t Detect Device: Ensure that Qualcomm drivers are installed properly. Sometimes, restarting both the PC and the OnePlus 11 5G can resolve the issue.
- Flashing Fails: If the flashing process fails mid-way, repeat the procedure or try using a different firmware version. Performing a factory reset after unbricking may also help.
Firmware Download to Unbrick OnePlus 11
China Version
PHB110domestic_11_A.13_2023050617380130.zip Download from Here
Global Variants:
CPH2447export_11_A.11_2023071921570000.zip Download from Here
CPH2449GDPR_11_A.27_2023101209280110.zip Download from Here
CPH2451export_11_A.21_2023060606000148.7z Download from Here
Tools
This is a Paid tool authorization is required.
Password: mgunlock.com
You can use our service below to unbrick OnePlus 11 5G
Contact Us on Telegram from here or WhatsApp from here If you need help.
Qualcomm, MTK platform – USB driver installation
- Download the driver file for How to Unbrick OnePlus 11 From Here
- Double-click to install (the default path does not need to be changed)
- Pop up a security window (always allow installation)
- Select restart the computer now
- Complete
How to reboot EDL
- Connect one end of the USB cable to your PC.
- Then connect the other end to your device.
- Now press and hold the Volume Up, Volume Down. after the software launches, remove your hands (or when you see qualcomm 9008 appear in device manager)
How to Unbrick OnePlus 11
- Download, Extract ROM File & tool in same folder
- Qualcomm_Drivers_QDLoader driver on your computer
- Login OplusFlashTool.exe
- Select Firmware
- Click “Start” button
- Conect Phone to PC, Enter EDL Mode
- Wait until success, once done. Unplug device and switch it ON >>>Done
OnePlus 11 Unbrick Service
15$
OnePlus 11 Unbrick Service
OnePlus 11 Unbrick PHB110, CPH2447, CPH2449, Stock ROM Firmware (Flash File). By using this firmware, you can solve all software issues within your OnePlus 11 5G, such as hanging on the logo, FRP reset, fixing stuck Fastboot Mode, bootloop (Lost Fastboot – Lost Recovery), stuck EDL (black screen) ocdt problem wifi network issues.
Qualcomm, MTK platform – USB driver installation
- Download the driver file From Here
- Double-click to install (the default path does not need to be changed)
- Pop up a security window (always allow installation)
- Select restart the computer now
- Complete
How to reboot EDL
- Connect one end of the USB cable to your PC.
- Then connect the other end to your device.
- Now press and hold the Volume Up, Volume Down, and Power keys. after the software launches, remove your hands (or when you see qualcomm 9008 appear in device manager)
