How to Unbrick OnePlus Ace 3 / 12R – PJE110, CPH2609, CPH2611, CPH2585 Stock ROM Firmware
How to Unbrick OnePlus Ace 3 / 12R (PJE110, CPH2609, CPH2611, CPH2585) Using Stock ROM Firmware (Flash File). This firmware can help resolve various software issues on your OnePlus Ace 3 / 12R, including problems like being stuck on the logo, FRP reset, resolving Fastboot mode issues, bootloops (Lost Fastboot or Recovery), getting stuck in EDL mode (black screen), a white screen after flashing, or being dead after flashing.
Table of Contents
Prerequisites for How to Unbrick OnePlus Ace 3 / 12R
Before starting the process, make sure you have the following:
- MSM Tool: The official Mobile Software Management tool from OnePlus. You can get this from official OnePlus sources or authorized distributors. It’s crucial to use the correct version specific to the OnePlus Ace 3/12R.
- A Windows PC: The MSM Tool is designed to run on Windows computers, so you’ll need a reliable PC running Windows 7 or later.
- USB Cable: A good-quality USB cable to connect the OnePlus Ace 3/12R to the PC.
- Battery Charged Above 10%: It’s best to ensure that the OnePlus Ace 3/12R has sufficient battery charge. If the phone is completely powered off or bricked, this is less critical, but it helps to prevent interruptions during the process.
- Qualcomm Drivers: These are essential for enabling the communication between the OnePlus Ace 3/12R and the computer. Install them before proceeding.
- Firmware for OnePlus Ace 3/12R: The correct firmware files for the device. If necessary, download the correct firmware package from trusted sources or OnePlus support channels.
Step-by-Step Process for How to Unbrick OnePlus Ace 3 / 12R Using the MSM Tool
- Download and Install the MSM Tool
Start by downloading the MSM Tool compatible with the OnePlus Ace 3/12R. Once downloaded, extract the zip file to a folder on your PC. - Install Qualcomm USB Drivers
Go to the Device Manager on your Windows PC.
Right-click the Start Menu, then select Device Manager.
Look for Unknown Device or your OnePlus Ace 3/12R under the “Ports” or “Other devices” section.
Right-click it, select Update Driver, and install Qualcomm USB drivers. You can download the drivers from trusted sources like the Qualcomm website. - Boot OnePlus Ace 3/12R into EDL (Emergency Download Mode)
OnePlus devices need to be in EDL mode to communicate with the MSM Tool. Here’s how you can put the OnePlus Ace 3/12R into EDL:- Power off the OnePlus Ace 3/12R completely.
- Hold down the Volume Up button and connect the phone to the PC using a USB cable.
- Once connected, the device should enter EDL mode, and the MSM Tool should detect the phone automatically.
- Launch the MSM Tool
After successfully connecting the OnePlus Ace 3/12R in EDL mode, open the MSM Tool you downloaded earlier. You should see an interface that detects your connected device. If it’s not detected, ensure that the Qualcomm drivers are correctly installed and try again. - Start the Unbricking Process
In the MSM Tool interface, you will see the Start or Download button. Click on it to begin the unbricking process.
The tool will start flashing the firmware to the OnePlus Ace 3/12R. This may take a few minutes, depending on the speed of your computer and the device. - Wait for the Process to Complete
During the flashing process, the MSM Tool will display progress in percentages. Be patient and do not disconnect the device during the process. Disconnecting the device prematurely may lead to further bricking or corruption of the system software. - Reboot the Device
Once the MSM Tool displays a message indicating the process is complete, you can safely disconnect the OnePlus Ace 3/12R from the PC. The device should now boot into the operating system, free from the bricked condition. If the device doesn’t boot immediately, a few more minutes of waiting may be needed.
Troubleshooting
- Device Not Entering EDL Mode: If the OnePlus Ace 3/12R isn’t entering EDL mode, double-check the steps or try using a different USB cable or port.
- MSM Tool Doesn’t Detect Device: Ensure that Qualcomm drivers are installed properly. Sometimes, restarting both the PC and the OnePlus Ace 3/12R can help.
- Flashing Fails: If the flashing fails mid-process, repeat the procedure or try a different firmware version. It may also help to perform a factory reset after unbricking.
Firmware Download to Unbrick OnePlus Ace 3/12R
China Version
PJE110domestic_11_14.0.0.317CN01_2024012904340000.zip Download from Here
Global Variants:
CPH2611export_11_14.0.0.307EX01_2024012713400107.zip Download from Here
CPH2609GDPR_11_14.0.0.307EX01_2024012713410000.zip Download from Here
Tools
This is a Paid tool authorization is required.
Password: mgunlock.com
You can use our service below to unbrick OnePlus Ace 3/12R 5G
Contact Us on Telegram from here or WhatsApp from here If you need help.
Qualcomm, MTK platform – USB driver installation
- Download the driver file for How to Unbrick OnePlus Ace 3 / 12R From Here
- Double-click to install (the default path does not need to be changed)
- Pop up a security window (always allow installation)
- Select restart the computer now
- Complete Now move to the next step for How to Unbrick OnePlus Ace 3 / 12R
How to reboot EDL
- Connect one end of the USB cable to your PC.
- Then connect the other end to your device.
- Now press and hold the Volume Up, Volume Down. after the software launches, remove your hands (or when you see Qualcomm 9008 appear in device manager) How to Unbrick OnePlus Ace 3 / 12R How to Unbrick OnePlus Ace 3 / 12R How to Unbrick OnePlus Ace 3 / 12R
How to Unbrick OnePlus Ace 3/12R
- Download, Extract ROM File & tool in same folder
- Qualcomm_Drivers_QDLoader driver on your computer
- Login OplusFlashTool.exe
- Select Firmware
- Click “Start” button
- Conect Phone to PC, Enter EDL Mode
- Wait until success, once done. Unplug device and switch it ON >>>Done All
OnePlus 12R/Ace 3 Unbrick Service
20$
OnePlus 12R/Ace 3 Unbrick Service
OnePlus 12R/Ace 3 Unbrick PJE110, CPH2609, CPH2611, CPH2585 Stock ROM Firmware (Flash File). By using this firmware, you can solve all software issues within your OnePlus 12R/Ace 3 Unbrick, such as hanging on the logo, FRP reset, fixing stuck Fastboot Mode, bootloop (Lost Fastboot – Lost Recovery), stuck EDL (black screen), or white after flashing, dead after flashing, etc.
Qualcomm, MTK platform – USB driver installation
- Download the driver file From Here
- Double-click to install (the default path does not need to be changed)
- Pop up a security window (always allow installation)
- Select restart the computer now
- Complete
How to reboot EDL
- Connect one end of the USB cable to your PC.
- Then connect the other end to your device.
- Now press and hold the Volume Up, Volume Down, and Power keys. after the software launches, remove your hands (or when you see qualcomm 9008 appear in device manager)
